Bistable relays RPB-1PM-...

Technical info


Connection diagrams bistable - impulse relays  RPB-1PM-A230, RPB-1PM-U24A

Schemat 1P, 1PM, 1ZI


Output circuit - contact data

Number and type of contacts

1 CO

Max. switching voltage

300 V AC/ 300 V DC

Rated load

AC1: 16 A / 250 V AC;  DC1: 16 A / 24 V DC

Max. inrush current

30 A

Coil data

Rated voltage

230 V AC, 24 V AC/DC

Rated power consumption

230 V AC - ≤ 0,5 W; 24 V AC/DC ≤ 0,8 W

Control contact S


ΣI < 5 mA

Min. voltage

0,85 Un

Min. time of pulse duration

≥ 55 ms

General data

Electrical life AC1

0,5 x 105  contact 1NO 16 A; 250 V AC

Mechanical life (cycles)


Ambient temperature - operating

-20...+55 o
