Bistable relay RPB-1ZMI-UNI
Bistable relay RPB-1ZMI-UNI
Bistable - impulse relays z pamięcią, relay with memory, RESISTANCE TO INRUSH CURRENT 80 A (20 ms), 1 NO, universal control voltage 12...240 V AC/DC.
Technical info
Bistable - impulse relays RPB-1ZMI-UNI cooperation with momentary (bell) switches or control buttons.
Connection diagrams bistable - impulse relays RPB-1ZI-UNI
| Output circuit - contact data |
||
| Number and type of contacts |
1 NO |
|
| Max. switching voltage |
300 V AC/ 300 V DC |
|
| Rated load |
AC1: 16 A / 250 V AC; DC1: 16 A / 24 V DC |
|
| Max. inrush current |
80 A 20 ms |
|
| Input circuit |
||
| Rated voltage |
230 V AC, 24 V AC/DC |
|
| Rated power consumption |
≤ 1,8 W |
|
| Control contact S |
||
| Load |
no |
|
| Min. voltage |
0,85 Un |
|
| Min. time of pulse duration |
≥ 55 ms |
|
| General data |
||
| Electrical life AC1 |
0,5 x 105 16 A; 250 V AC |
|
| Mechanical life (cycles) |
107 |
|
| Ambient temperature - operating |
-20...+55 oC |
|
